The Ashcroft® 1005, 1005P and 1005S Series pressure gauges combine an aesthetic design with reliability and performance. Easily customizable, the extensive variety of case materials, connection locations and ranges, make these models an ideal solution for many pressure measurement installations.

Ashcroft® 1005H Commercial Pressure Gauge, 2-1/2 IN Dial, 30 PSI Measuring, Units Of Measure: PSI, 1/4 IN MNPT Lower Connection, Plus/Minus 3-2-3% Of Span (ASME B40.100 Grade B) Accuracy, Aluminum, Black Figures on White Background Dial Face, Steel Case, Pointer Material: Aluminum, Movement Material: PowerFlex™ With Polyester Segment, Bronze Tube, Finish/Color: Painted Black, Filled With: Dry, -40 - 150 DEG F, 2.73 IN Width, 1.1 IN Depth, Industry Standards: CRN, UL 252A, UL 404 Listed, Additional Specifications: Connection Material: Brass, Window Material: Polycarbonate

• PowerFlex™ movement provides superior-resistance to shock, vibration and pulsation, extends product life and reduces maintenance costs
• True Zero™ reduces reading errors by using a "zero box" instead of conventional dial pins (posts), this ensures product safety, integrity and system control
• FlutterGuard™ option reduces movement wear and eliminates pointer flutter, extends product life and allows easy gauge readability

• Installation Instruction Name https://macombstage.cimm2.com//ASSETS/DOCUMENTS/ITEMS/EN/GA25100502L030_Inst.pdf
• Specification Name https://macombstage.cimm2.com//ASSETS/DOCUMENTS/ITEMS/EN/GA25100502L030_Spec.pdf
