RMC141 RATE-MASTER FLOWMETER 0.1 - 1 GPM

The series RM Rate-Master® flowmeters are a line of general use, direct reading precision flowmeters suitable for both gas and liquid applications. This series consists of 2 IN (51 MM), 5 IN (127 MM) and 10 IN (254 MM) scales that can be panel or surface mounted with optional precision metering valves. Within a given Series, the Rate-Master® flowmeter bodies can be instantly interchanged, allowing the piping to remain undisturbed, interchangeability of the ranges, and easy cleaning. The Rate-Master® flowmeter bodies can be instantly interchanged with in the same series scale size, allowing the piping to remain undisturbed, interchangeability of the ranges, and easy cleaning.

Rate-Master® Flowmeter, Series/Model: Model RMC, Connection Size: 1/2 IN FNPT, 0.1 - 1 GPM Flow Range, Polycarbonate Housing, Flow Material: Water, Wetted Materials: Neoprene And Buna-N O-Ring, Stainless Steel Metal Parts, Stainless Steel Float, Black Glass, Aluminum, K Monel, Tungsten Carbide, Accuracy: 2% Of Full Scale, Pressure Rating: 100 PSI, Temperature Rating: 130 DEG F, Length: 15-3/8 IN, 2-1/4 IN Width, Industry Standards: RoHS Compliant, Additional Specifications: 10 IN Scale

• Eliminate the need for troublesome conversions with direct reading scales
• Reduce installation damage and cost due to stainless steel backbone that absorbs piping torque
• Long operation life with durable, shatter-proof polycarbonate body
• High repeatability enabled by precision injection molding around a precision tapered pin
• Increased reading accuracy with special integral flow guides that stabilize float movement
• Save time with instantaneous flow reading from scale graduations on both sides of the indicating tube

• Catalog https://macombstage.cimm2.com//ASSETS/DOCUMENTS/ITEMS/EN/Dwyer_RMC141_Catalog.pdf
• Instruction/Installation Manual https://macombstage.cimm2.com//ASSETS/DOCUMENTS/ITEMS/EN/Dwyer_RMC141_Instruction_Installation_Manual.pdf
• Specification Sheet https://macombstage.cimm2.com//ASSETS/DOCUMENTS/ITEMS/EN/Dwyer_RMC141_Specification_Sheet.pdf
• Technical Drawing https://macombstage.cimm2.com//ASSETS/DOCUMENTS/ITEMS/EN/RMC141_Tech.pdf
