7/8 FIG 62 JR. TOP BEAM CLA
Empire Industries FIG 62 62B0078 Beam Clamp, 7/8-9 Rod, 8 IN Conduit/Pipe, 1130 LB, Ductile Iron, Plain
- Manufacturer: Empire Industries Inc
- Brand: Empire Industries
- MGPN: HGR TOP BEAM JR 7/8
- MPN: 62B0078
- UPC: 663027039653
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Designed to attach hanger rod to the top or bottom flange of a beam or bar joist where flange thickness does not exceed 5/8 IN.
Empire Industries FIG 62 Small Mouth Beam Clamp, 7/8-9 Rod, Conduit/Pipe Size: 8 IN, Maximum Load: 1130 LB, Ductile Iron, Industry Standards: Federal Specification A-A-1192 A (Type #19), MSS-SP58 and MSS-SP69 (Type #19), Finish/Color: Plain, 2-3/8 IN Width, Other Physical Dimension: 1-7/8 IN Height
| Item Name | : | Beam Clamp |
| Type | : | Small Mouth |
| Series/Model | : | FIG 62 |
| Rod Size | : | 7/8-9 |
| Conduit/Pipe Size | : | 8 IN |
| Maximum Load | : | 1130 LB |
| Material | : | Ductile Iron |
| Industry Standards | : | Federal Specification A-A-1192 A (Type #19), MSS-SP58 and MSS-SP69 (Type #19) |
| Finish/Color | : | Plain |
| Width | : | 2-3/8 IN |
| Other Physical Dimension | : | 1-7/8 IN Height |
