Jomar JF-100T 100-104-TH 2-Piece Ball Valve, 3/4 IN, Threaded, Brass, Class 600
3/4 JOMAR JF-100T BALL VLV W/T HDL
- Manufacturer: Jomar Valves
- Brand: Jomar
- MGPN: VLV BA BR JOMAR 100-104TH 3/4
- MPN: 100-104-TH
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Jomar 2-Piece Ball Valve, Type: Full Port, Brand Name: Jomar, Item Name: 2-Piece Ball Valve, Series/Model: JF-100T, 3/4 IN Nominal, Threaded Connection, Pressure Class: Class 600, Brass Body, Steel Handle, Brass Stem, PTFE Packing, Brass Gland, PTFE Seat, Material Standard: C37700, Industry Standards: ANSI B1.20.1, ASME B16.33, CSA Certified, FM Approved, MSS SP-110, UL Listed, Proposition 65 Warning - This Product Can Expose You - Chemicals Including Lead, Which is Known - the State of California - Cause Cancer, Birth Defects or Other Reproductive Harm, 2.52 IN Width, Other Physical Dimension: 2.36 IN Center To Top, Additional Specifications: Handle Type: T-Handle, Ball Material: Chrome-Plated Brass
| Brand Name | : | Jomar |
| Item Name | : | 2-Piece Ball Valve |
| Type | : | Full Port |
| Series/Model | : | JF-100T |
| Nominal Size | : | 3/4 IN |
| Connection Type | : | Threaded |
| Pressure Class | : | Class 600 |
| Body Material | : | Brass |
| Handle Material | : | Steel |
| Stem Material | : | Brass |
| Packing Material | : | PTFE |
| Gland Material | : | Brass |
| Seat Material | : | PTFE |
| Material Standard | : | C37700 |
| Industry Standards | : | ANSI B1.20.1, ASME B16.33, CSA Certified, FM Approved, MSS SP-110, UL Listed, Proposition 65 Warning - This Product Can Expose You - Chemicals Including Lead, Which is Known - the State of California - Cause Cancer, Birth Defects or Other Reproductive Harm |
| Width | : | 2.52 IN |
| Other Physical Dimension | : | 2.36 IN Center To Top |
| Additional Specifications | : | Handle Type: T-Handle, Ball Material: Chrome-Plated Brass |
- Gland follower and single O-ring stem design
- Blowout-proof stem design
- 100% leak tested
