PS10-1 PRESSURE SWITCH

The Potter PS10 series pressure actuated switches are designed for the detection of a water flow condition in automatic fire sprinkler systems of particular designs such as wet pipe systems with alarm check valves, dry pipe, reaction, or deluge valves. The PS10 is also suitable to provide a low-pressure supervisory signal, adjustable between 4 and 15 PSI.

POTTER® Pressure Switch, Pressure Switch, Series/Model: Model PS10, 125/250 VAC, 30 VDC, 10.1 A At 125/250 VAC, 2 A At 30 VDC, Composite/Die Cast, Industry Standards: cULus Listed, CE Marked, FM Approved, LPCB, Other Physical Dimension: 3.78 IN Width, 3.2 IN Depth, 4.22 IN Height, Additional Specifications: Temperature Range: -40 To 140 DEG F, Pressure Range: 4 - 15 PSI, Contact Configuration: (2) SPDT

• Independent switch adjustment on two switch models, no tools needed
• Two 1/2 IN conduit/cable entrances
• Separate isolated wiring chambers
• Non-corrosive pressure connection
• Non-conductive enclosure
