12 VELAN F18-1064C-02TY 300
Velan F18-1064C-02TY Gate Valve, 12 IN, Flanged, Wrought Carbon Steel, 85 - 740 PSI
- Manufacturer: Velan Valve Corporation
- Brand: Velan
- MGPN: VLV GT CS 300 FLGD 12
- MPN: F18-1064C-02TY
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Velan bolted bonnet flexible wedge gate valves are ideal for high pressure steam, catalytic reformers, hydrocrackers and other tough services.
Velan Bolted Bonnet Forged Flexible Wedge Full Port Gate Valve, 12 IN Nominal, Flanged Connection, 85 - 740 PSI, Pressure Class: Class 300, -20 - 1000 DEG F, Wrought Carbon Steel Body, Handwheel Operator, Stainless Steel Stem, Stainless Steel Trim, Alloy Stainless Steel Seat, Other Physical Dimension: 59 IN Top To Inlet Center, 19-3/4 IN Inlet To Outlet Length, Additional Specifications: Media: Gas, Oil and Water
| Item Name | : | Gate Valve |
| Type | : | Bolted Bonnet Forged Flexible Wedge, Full Port |
| Nominal Size | : | 12 IN |
| Connection Type | : | Flanged |
| Pressure Rating | : | 85 - 740 PSI |
| Pressure Class | : | Class 300 |
| Temperature Rating | : | -20 - 1000 DEG F |
| Body Material | : | Wrought Carbon Steel |
| Operator Type | : | Handwheel |
| Stem Material | : | Stainless Steel |
| Trim Material | : | Stainless Steel |
| Seat Material | : | Alloy Stainless Steel |
| Other Physical Dimension | : | 59 IN Top To Inlet Center, 19-3/4 IN Inlet To Outlet Length |
| Additional Specifications | : | Media: Gas, Oil and Water |
- Stronger, leak-proof bolted body bonnet joint ensures joint tightness with a higher bolting torque
- Wedge guiding minimizes seat rubbing and scuffing resulting in long cycle life
- Designed to ASME B16.34
- Body made of superior strength forgings and optional cast steel
- Velan stem seal offers tight seal with little to no maintenance over long periods of time
- Optional live loading of packing and leak-off
- Non-rotating stem
- Hard faced seating faces resist erosion
