3 VIC 110 L/R 45 ELL
Victaulic Model 110 F030110P00 Long Radius 45 DEG Elbow, 3 IN, Grooved, Ductile Iron, Orange Enamel Painted
- Manufacturer: Victaulic Company
- Brand: Victaulic
- MGPN: VIC ELL 110 3
- MPN: F030110P00
- UPC: 688304054273
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Victaulic Long Radius 45 DEG Elbow, Long Radius 45 DEG Elbow, Series/Model: Model 110, 3 IN Nominal, Connection Type: Grooved, Ductile Iron, Material Standard: ASTM A536 Grade 65-45-12, Finish/Color: Orange Enamel Painted, 3-1/2 IN Outside Diameter, 1000 PSI Maximum Pressure, Industry Standards: CE EN 10311 CPR (EU) No 305/2011, Other Physical Dimension: 3.38 IN Center To End, Additional Specifications: Suitable For Use With: Victaulic Couplings, Valves, 3.750 LB Weight
| Item Name | : | Long Radius 45 DEG Elbow |
| Series/Model | : | Model 110 |
| Nominal Size | : | 3 IN |
| Connection Type | : | Grooved |
| Material | : | Ductile Iron |
| Material Standard | : | ASTM A536 Grade 65-45-12 |
| Finish/Color | : | Orange Enamel Painted |
| Outside Diameter | : | 3-1/2 IN |
| Maximum Pressure | : | 1000 PSI |
| Industry Standards | : | CE EN 10311 CPR (EU) No 305/2011 |
| Other Physical Dimension | : | 3.38 IN Center To End |
| Additional Specifications | : | Suitable For Use With: Victaulic Couplings, Valves |
| Weight | : | 3.750 LB |
- Standard fitting pressure ratings conform to ratings of installed coupling
- All fittings supplied with grooves or shoulders for fast installation
