14 VIC W13 11-1/4 ELL
Victaulic AGS® Model W13 W140013P00 11-1/4 DEG Elbow, 14 IN, Grooved, Carbon Steel, Orange Enamel Painted
- Manufacturer: Victaulic Company
- Brand: Victaulic
- MGPN: VIC ELL W13 14
- MPN: W140013P00
- UPC: 688304872839
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Victaulic AGS® 11-1/4 DEG Elbow, AGS®, 11-1/4 DEG Elbow, Series/Model: Model W13, 14 IN Nominal, Connection Type: Grooved, Carbon Steel, Material Standard: ASTM A53 Type E Or S, Grade B Or API-5L, PSL 1 Or PSL 2, Finish/Color: Orange Enamel Painted, Method Of Manufacturer: Segmentally Welded, 14 IN Outside Diameter, 350 PSI Maximum Pressure, Industry Standards: cUL Listed, FM Approved, Other Physical Dimension: 3-1/2 IN Center To End, Additional Specifications: Suitable For Use With: Victaulic Couplings, Valves, Accessories And Pipe, 32.000 LB Weight
| Sub Brand | : | AGS® |
| Item Name | : | 11-1/4 DEG Elbow |
| Series/Model | : | Model W13 |
| Nominal Size | : | 14 IN |
| Connection Type | : | Grooved |
| Material | : | Carbon Steel |
| Material Standard | : | ASTM A53 Type E Or S, Grade B Or API-5L, PSL 1 Or PSL 2 |
| Finish/Color | : | Orange Enamel Painted |
| Method Of Manufacturer | : | Segmentally Welded |
| Outside Diameter | : | 14 IN |
| Maximum Pressure | : | 350 PSI |
| Industry Standards | : | cUL Listed, FM Approved |
| Other Physical Dimension | : | 3-1/2 IN Center To End |
| Additional Specifications | : | Suitable For Use With: Victaulic Couplings, Valves, Accessories And Pipe |
| Weight | : | 32.000 LB |
- Fitting pressure ratings are equivalent to the AGS coupling used to install them
- Grooved ends eliminate pipe end preparation for the fittings
