1/4 APOLLO 94MBV02 MXF BRZ MINI BALL
Apollo Valves 94MBV Series 94MBV02 Ball Valve, Mini, Full Port, 1/4 X 1/4 IN, MNPT X FNPT, 600 PSI, -40 to 300 DEG F
- Manufacturer: Aalberts integrated piping systems (CONBRACO)
- Brand: Apollo Valves
- MGPN: VLV BA BR 94MBV02 1/4
- MPN: 94MBV02
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Apollo Valves Ball Valve, Type: Mini, Full Port, Item Name: Ball Valve, Series/Model: 94MBV Series, 1/4 X 1/4 IN Nominal, MNPT X FNPT Connection, 600 PSI, -40 to 300 DEG F, Brass Body, Reversible Handle Operator, Brass Stem, TFE Seat, Finish/Color: Yellow, Industry Standards: ANSI Z21.15-2009/CSA 9.1-2009, ASME B16.44-2002, MSS-SP-110, Prop 65 Warning, Other Physical Dimension: 1.95 IN Inlet to Outlet Length, 1.09 IN Top to Inlet Center
| Item Name | : | Ball Valve |
| Type | : | Mini, Full Port |
| Series/Model | : | 94MBV Series |
| Nominal Size | : | 1/4 X 1/4 IN |
| Connection Type | : | MNPT X FNPT |
| Pressure Rating | : | 600 PSI |
| Temperature Rating | : | -40 to 300 DEG F |
| Body Material | : | Brass |
| Operator Type | : | Reversible Handle |
| Stem Material | : | Brass |
| Seat Material | : | TFE |
| Finish/Color | : | Yellow |
| Industry Standards | : | ANSI Z21.15-2009/CSA 9.1-2009, ASME B16.44-2002, MSS-SP-110, Prop 65 Warning |
| Other Physical Dimension | : | 1.95 IN Inlet to Outlet Length, 1.09 IN Top to Inlet Center |
- The 94MBV series is a heavy pattern two-piece forged brass full port ball valve designed for water, oil or gas in commercial and light industrial applications
- Blowout-proof stem
- Double viton O-ring stem seals
- Large raised wrench flats
