ASHCROFT GAUGE
Ashcroft® 1490 251490A02L100IW Diaphragm Gauge, 2-1/2 IN Dial, 0 - 100 IN H2O, IN H2O, 1/4 IN MNPT Lower
- Manufacturer: Ashcroft Inc
- Brand: Ashcroft®
- MGPN: GA25149002L 100-H2O
- MPN: 251490A02L100IW
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Ashcroft® 1490 diaphragm gauge is a cost effective solution for low pressure measurement applications. It provides reliability and accurate performance due to its ultra-sensitive diaphragm measuring system. An ideal gauge for non-corrosive gas measurement.
Ashcroft® 1490 Low Pressure Diaphragm Gauge, 2-1/2 IN Dial, 0 - 100 IN H2O Measuring, Units Of Measure: IN H2O, 1/4 IN MNPT Lower Connection, Plus/Minus 2%-1%-2% Of Span (ASME B40.100 Grade A) Accuracy, Aluminum, White Background, Black Figures and Intervals Dial Face, Glass Filled Polysulfone Case, Pointer Material: Aluminum, Movement Material: Brass, Mounting: Flush U-Clamp, Stem, Additional Specifications: Window Material: Polycarbonate
| Item Name | : | Diaphragm Gauge |
| Type | : | Low Pressure |
| Series/Model | : | 1490 |
| Dial Size | : | 2-1/2 IN |
| Measuring Range | : | 0 - 100 IN H2O |
| Units Of Measure | : | IN H2O |
| Connection | : | 1/4 IN MNPT Lower |
| Accuracy | : | Plus/Minus 2%-1%-2% Of Span (ASME B40.100 Grade A) |
| Dial Face | : | Aluminum, White Background, Black Figures and Intervals |
| Case Material | : | Glass Filled Polysulfone |
| Pointer Material | : | Aluminum |
| Movement Material | : | Brass |
| Mounting | : | Flush U-Clamp, Stem |
| Additional Specifications | : | Window Material: Polycarbonate |
- Easily removable polycarbonate window for small zero adjustments
- FlutterGuard™ option reduces movement wear and eliminates pointer flutter, extends product life and allows easy gauge readability
- Case is suitable for intermittent or continuous services on natural gas
