4-1/2 DIAL 1/2L CONN FLOUROLUBE FILLED
Ashcroft® Duragauge® Model 1279 451279SSL04L100# Pressure Gauge, 4-1/2 IN Dial, 0 - 100 PSI, 1/2 IN MNPT Lower
- Manufacturer: Ashcroft Inc
- Brand: Ashcroft
- MGPN: GA451279SSL04L 0-100 FILLED
- MPN: 451279SSL04L100#
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Ashcroft® 1279 Duragauge® is a high-performance 4-1/2 IN ASME style process pressure gauge with a comprehensive design for maximizing safety and reliability. Features include a solid front case and a 10 years pressure system warranty.
Ashcroft® Duragauge® Pressure Gauge, Duragauge®, Pressure Gauge, Series/Model: Model 1279, 4-1/2 IN Dial, 0 - 100 PSI Measuring, Units Of Measure: PSI, 1/2 IN MNPT Lower Connection, Plus/Minus 0.5% Of Span (ASME B40.100 Grade 2A) Accuracy, Aluminum Dial Face, Phenolic Case, Glass Lens, Aluminum Pointer, Movement Material: 400 Stainless Steel, 316 Stainless Steel Tube, 316L Stainless Steel Socket, Finish/Color: Black, Filled With: Glycerin, Flush, Stem, Surface Mounting, 20 - 150 DEG F, 5.81 IN Length, 5.81 IN Width, 3.36 IN Depth, Industry Standards: ASME B40.100, CE Marked, CRN Approved, UL 94-V-0, NSF-61 Certified
| Sub Brand | : | Duragauge® |
| Item Name | : | Pressure Gauge |
| Series/Model | : | Model 1279 |
| Dial Size | : | 4-1/2 IN |
| Measuring Range | : | 0 - 100 PSI |
| Units Of Measure | : | PSI |
| Connection | : | 1/2 IN MNPT Lower |
| Accuracy | : | Plus/Minus 0.5% Of Span (ASME B40.100 Grade 2A) |
| Dial Face | : | Aluminum |
| Case Material | : | Phenolic |
| Lens Material | : | Glass |
| Pointer Material | : | Aluminum |
| Movement Material | : | 400 Stainless Steel |
| Tube Material | : | 316 Stainless Steel |
| Socket Material | : | 316L Stainless Steel |
| Finish/Color | : | Black |
| Filled With | : | Glycerin |
| Mounting | : | Flush, Stem, Surface |
| Temperature Rating | : | 20 - 150 DEG F |
| Length | : | 5.81 IN |
| Width | : | 5.81 IN |
| Depth | : | 3.36 IN |
| Industry Standards | : | ASME B40.100, CE Marked, CRN Approved, UL 94-V-0, NSF-61 Certified |
- Solid front case design for safety
- Micrometer adjustable pointer
- Pressure range from vacuum to 30000 PSI
- NSF-61 compliant
