ASHCROFT GAUGE
Ashcroft® Duragauge® Model 2462 452462AS02L30IMV&60# Pressure Gauge, 4-1/2 IN Dial, 30 - 0 IN Hg, 0 - 60 PSI
- Manufacturer: Ashcroft Inc
- Brand: Ashcroft
- MGPN: GA452462AS02L 30-60
- MPN: 452462AS02L30IMV&60#
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Ashcroft® 2462 Duragauge® is a high-performance 6 IN ASME style process pressure gauge with a comprehensive design for maximizing safety and reliability. Features include a solid front case and a 10 years pressure system warranty.
Ashcroft® Duragauge® Pressure Gauge, Duragauge®, Pressure Gauge, Series/Model: Model 2462, 4-1/2 IN Dial, 30 - 0 IN Hg, 0 - 60 PSI Measuring, Units Of Measure: IN Hg, PSI, 1/4 IN MNPT Lower Connection, Plus/Minus 0.5% Of Span (ASME B40.100 Grade 2A) Accuracy, Aluminum Dial Face, Polypropylene Case, Glass Lens, Aluminum Pointer, Movement Material: 400 Stainless Steel, Bronze Tube, Brass Socket, Filled With: Dry, Flush, Stem, Surface Mounting, -20 To 250 DEG F, Industry Standards: ASME B40.100, CE Marked, CRN Approved, UKCA Approved
| Sub Brand | : | Duragauge® |
| Item Name | : | Pressure Gauge |
| Series/Model | : | Model 2462 |
| Dial Size | : | 4-1/2 IN |
| Measuring Range | : | 30 - 0 IN Hg, 0 - 60 PSI |
| Units Of Measure | : | IN Hg, PSI |
| Connection | : | 1/4 IN MNPT Lower |
| Accuracy | : | Plus/Minus 0.5% Of Span (ASME B40.100 Grade 2A) |
| Dial Face | : | Aluminum |
| Case Material | : | Polypropylene |
| Lens Material | : | Glass |
| Pointer Material | : | Aluminum |
| Movement Material | : | 400 Stainless Steel |
| Tube Material | : | Bronze |
| Socket Material | : | Brass |
| Filled With | : | Dry |
| Mounting | : | Flush, Stem, Surface |
| Temperature Rating | : | -20 To 250 DEG F |
| Industry Standards | : | ASME B40.100, CE Marked, CRN Approved, UKCA Approved |
- Wide selection of bourdon tube materials, pressure connections and pressure ranges
- Solid front case design for safety
- Teflon-coated, 400 stainless steel movement
Installation Instruction Name
