1/2 GAS VALVE
Mueller ProLine® 7701G Forged Brass 1-Piece Flat/Square Head Gas Ball Valve, 1/2 IN, FNPT
- Manufacturer: Macomb Group Approved
-
Brand:
Macomb Group Approved™
MACOMB GROUP APPROVED™ identifies a product sold by The Macomb Group that complies with the form, fit, and function of the products responsive to your search request.
- MGPN: 050113523GV
- MPN: 113-523
- UPC: 032888135239
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
ProLine® 1-Piece Flat/Square Head Gas Ball Valve, Series/Model: Series 7701G, Nominal Size: 1/2 IN, Connection Type: FNPT, Pressure Rating: 200 PSI, Temperature Rating: -20 To 300 DEG F, Forged Brass Body Material, Industry Standards: ANSI B1.20.1, CSA Certified, ANSI Z21.15, ANSI/ASME B16.44, UL Listed, Lead Free: No
| Body Material | : | Forged Brass |
| Connection Type | : | FNPT |
| Industry Standards | : | ANSI B1.20.1, CSA Certified, ANSI Z21.15, ANSI/ASME B16.44, UL Listed |
| Item Name | : | Flat/Square Head Gas Ball Valve |
| Lead Free | : | No |
| Nominal Size | : | 1/2 IN |
| Pressure Rating | : | 200 PSI |
| Series/Model | : | Series 7701G |
| Sub Brand | : | ProLine® |
| Temperature Rating | : | -20 To 300 DEG F |
| Type | : | 1-Piece |
| Weight | : | 37.000 LB |
- Flat head operation prevents unintentional operation valve
- 1/4 turn operation
- Multi-directional flow
- 1-piece body for leak resistance and long valve life
- Chrome plated brass ball
