4 0-600 PSI DRY PRESSURE GAUGE U-CLAMP 1/4 BM

Industrial Pressure Gauge, Series/Model: Model 700B, 4 IN Dial, Measuring Range: 0 - 600 PSI, Units Of Measure: PSI, Connection: 1/4 IN MNPT Lower Back, Accuracy: Plus/Minus 1% Full Scale (ASME Grade 1A), Graduations: 10 Smallest, 100 Largest, Dial Face: Aluminum, White Background With Black Graduations And Markings, Satin 304 Stainless Steel Case, Laminated Safety Glass Lens, Brass Movement, Tube Material: Bronze, Brass Socket, Dry Filled With, Mounting: U-Clamp, Temperature Rating: 150 DEG F, Length: 3.98 IN, 3.98 IN Width, 2.24 IN Depth, Industry Standards: ASME B40.100, CRN Approved

The Trerice 700 series industrial gauge is designed for the varying needs of the world's industrial applications. This gauge has a stainless steel case and ring. Its sturdy interior design and field liquid-fill capability (no kit required) provide the durability and accuracy required for industrial process environments. Available wetted parts are bronze tube with lead-free (PBF) brass socket, stainless steel tube and socket, or monel tube and socket.

• Field liquid fillable
• Stainless steel case

• Catalog https://macombstage.cimm2.com//ASSETS/DOCUMENTS/ITEMS/EN/Trerice_107-001_Catalog.pdf
• Instruction/Installation Manual https://macombstage.cimm2.com//ASSETS/DOCUMENTS/ITEMS/EN/4500200PPGS_Inst.pdf
• Specification Sheet https://macombstage.cimm2.com//ASSETS/DOCUMENTS/ITEMS/EN/Trerice_700B4002BA130UCB_Specification_Sheet.pdf
